Disconnected Catalogs and Operators

A part from Openshift services, there are pods which are continuosly updating. They are the Operators Catalogs. These are pod where are defined the Operators that you can see, for example, in the Operator Hub.

$ oc get catalogsource -A
NAMESPACE               NAME                  DISPLAY               TYPE   PUBLISHER   AGE
openshift-marketplace   certified-operators   Certified Operators   grpc   Red Hat     17h
openshift-marketplace   community-operators   Community Operators   grpc   Red Hat     17h
openshift-marketplace   redhat-marketplace    Red Hat Marketplace   grpc   Red Hat     17h
openshift-marketplace   redhat-operators      Red Hat Operators     grpc   Red Hat     17h

Before these catalogs/pods were sqlite-based catalogs. A sqlite database storaged all information about Operators, Channels, Versions, dependencies,…​ Now in 4.11+ the sqlite database has been replaced by a file base. All methods we had to create new custom catalogs it’s not valid (opm, for example). Following, the options we have in a disconnected installation:

There are 3 options for catalogs in disconnected:

  1. Default catalogs with images mirrored and registry mirror config

  2. Default catalogs with images mirrored and Custom catalogs

  3. Build a custom catalog

But apart from the catalogs themself, we would need the images that Operators need to get run. Here, nowadays we have 2 options for mirroring of images from operators.

  1. with command oc

  2. with oc-mirror

Firstly, the Catalogs Sources:

Disconnected Catalogs

We have our new disconnected Openshift deployment. Export KUBECONFIG variable to point to it:

export KUBECONFIG=/root/.kcli/clusters/lab-test-disconnected/auth/kubeconfig

If you check the operator catalogs pods in your cluster you will see:

$ oc get pod -n openshift-marketplace
NAME                                    READY   STATUS             RESTARTS   AGE
certified-operators-dh7kf               0/1     ImagePullBackOff   0          20h
certified-operators-f5xcm               0/1     ImagePullBackOff   0          18h
community-operators-6lw8k               0/1     ImagePullBackOff   0          20h
community-operators-jrdl4               0/1     ImagePullBackOff   0          18h
marketplace-operator-7696c9454c-b4zwl   1/1     Running            2          18h

All pods are in ImagePullBackOff status. Let’s see how to solve it:

Default catalogs with images mirrored and registry mirror config

This option is based on mirroring of catalog images, and then use a registry mirror config with a machineConfig object. We do not use ImageContentSourcePolicy because catalog are using tags reference in the images instead of digest:

  • Mirror catalogs images using oc-mirror. Create a imageset file (7-imageset-config-catalogs.yaml):

    kind: ImageSetConfiguration
apiVersion: mirror.openshift.io/v1alpha2
archiveSize: 10
storageConfig:
  registry:
    imageURL: registry.dsal:8443/imagetset/mirror-catalog:metadata
    skipTLS: true
mirror:
  additionalImages:
  - name: registry.redhat.io/redhat/redhat-operator-index:v4.11
  - name: registry.redhat.io/redhat/redhat-marketplace-index:v4.11
  - name: registry.redhat.io/redhat/community-operator-index:v4.11
  - name: registry.redhat.io/redhat/certified-operator-index:v4.11

  • Run mirror command

    oc-mirror --config=./7-imageset-config-catalogs.yaml  docker://registry.dsal:8443/mirror

  • Create a new registry-conf-operators.txt file because these images (catalog images) references are tags instead of digest:

    [[registry]]
  prefix = ""
  location = "registry.redhat.io/redhat"
  mirror-by-digest-only = false

[[registry.mirror]]
location = "registry.dsal:8443/mirror/redhat"

  • Get base64 from this file:

    cat registry-conf-operators.txt | base64 -w0
    W1tyZWdpc3RyeV1dCiAgcHJlZml4ID0gIiIKICBsb2NhdGlvbiA9ICJyZWdpc3RyeS5yZWRoYXQuaW8vcmVkaGF0IgogIG1pcnJvci1ieS1kaWdlc3Qtb25seSA9IGZhbHNlCgpbW3JlZ2lzdHJ5Lm1pcnJvcl1dCmxvY2F0aW9uID0gInJlZ2lzdHJ5LmRzYWw6ODQ0My9taXJyb3IvcmVkaGF0Igo=

  • Create machine-config file 7-mc-99-operators-registries.yaml:

    apiVersion: machineconfiguration.openshift.io/v1
kind: MachineConfig
metadata:
  labels:
    machineconfiguration.openshift.io/role: master
  name: 99-operators-registries
spec:
  config:
    ignition:
      version: 3.1.0
    storage:
      files:
      - contents:
          source: data:text/plain;charset=utf-8;base64,W1tyZWdpc3RyeV1dCiAgcHJlZml4ID0gIiIKICBsb2NhdGlvbiA9ICJyZWdpc3RyeS5yZWRoYXQuaW8vcmVkaGF0IgogIG1pcnJvci1ieS1kaWdlc3Qtb25seSA9IGZhbHNlCgpbW3JlZ2lzdHJ5Lm1pcnJvcl1dCmxvY2F0aW9uID0gInJlZ2lzdHJ5LmRzYWw6ODQ0My9taXJyb3IvcmVkaGF0Igo=
        filesystem: root
        mode: 420
        path: /etc/containers/registries.conf.d/99-operators-registries.conf

  • and apply it

    oc apply -f 7-mc-99-operators-registries.yaml

    Now, wait for MachineConfigPool to be updated in all nodes (It will reboot node(s)).

  • Delete pods from openshift-markeplace namespace to force update

    oc delete --all pods -n openshift-marketplace

    Wait some seconds to see pod running again:

    $ oc get pod -n openshift-marketplace
NAME                                    READY   STATUS    RESTARTS   AGE
certified-operators-fg98d               1/1     Running   0          15s
community-operators-qf9jm               1/1     Running   0          15s
marketplace-operator-6f9748c96f-bwlkq   1/1     Running   0          17s
redhat-marketplace-nb7hw                1/1     Running   0          14s
redhat-operators-qx9rd                  1/1     Running   0          14s

Now we have all our catalogs running with mirrored images. Let’s go to the next method:

Default catalogs with images mirrored and custom catalogs

The second method would be creating custom catalogs based on default ones.

In the first method we did a mirror of the catalog images. We already have the images copied to our private registry, so we can simply create catalogs that point to these images. Follow the next steps:

  • Disable default catalogs:

    oc patch OperatorHub cluster --type json \
    -p '[{"op": "add", "path": "/spec/disableAllDefaultSources", "value": true}]'

  • Create new catalogs files 7-default-catalogsources.yaml, just replacing public images for mirrored images in registry.dsal:8443/mirror registry:

    apiVersion: v1
kind: List
metadata:
  resourceVersion: ""
  selfLink: ""
items:
- apiVersion: operators.coreos.com/v1alpha1
  kind: CatalogSource
  metadata:
    name: mirror-certified-operators
    namespace: openshift-marketplace
  spec:
    displayName: Mirror Certified Operators
    grpcPodConfig:
      nodeSelector:
        kubernetes.io/os: linux
        node-role.kubernetes.io/master: ""
      tolerations:
      - effect: NoSchedule
        key: node-role.kubernetes.io/master
        operator: Exists
      - effect: NoExecute
        key: node.kubernetes.io/unreachable
        operator: Exists
        tolerationSeconds: 120
      - effect: NoExecute
        key: node.kubernetes.io/not-ready
        operator: Exists
        tolerationSeconds: 120
    image: registry.dsal:8443/mirror/redhat/certified-operator-index:v4.11
    publisher: Custom
    sourceType: grpc
    updateStrategy:
      registryPoll:
        interval: 10m0s
- apiVersion: operators.coreos.com/v1alpha1
  kind: CatalogSource
  metadata:
    name: mirror-community-operators
    namespace: openshift-marketplace
  spec:
    displayName: Mirror Community Operators
    grpcPodConfig:
      nodeSelector:
        kubernetes.io/os: linux
        node-role.kubernetes.io/master: ""
      priorityClassName: system-cluster-critical
      tolerations:
      - effect: NoSchedule
        key: node-role.kubernetes.io/master
        operator: Exists
      - effect: NoExecute
        key: node.kubernetes.io/unreachable
        operator: Exists
        tolerationSeconds: 120
      - effect: NoExecute
        key: node.kubernetes.io/not-ready
        operator: Exists
        tolerationSeconds: 120
    image: registry.dsal:8443/mirror/redhat/community-operator-index:v4.11
    publisher: Custom
    sourceType: grpc
    updateStrategy:
      registryPoll:
        interval: 10m0s
- apiVersion: operators.coreos.com/v1alpha1
  kind: CatalogSource
  metadata:
    name: mirror-redhat-marketplace
    namespace: openshift-marketplace
  spec:
    displayName: Mirror Red Hat Marketplace
    grpcPodConfig:
      nodeSelector:
        kubernetes.io/os: linux
        node-role.kubernetes.io/master: ""
      tolerations:
      - effect: NoSchedule
        key: node-role.kubernetes.io/master
        operator: Exists
      - effect: NoExecute
        key: node.kubernetes.io/unreachable
        operator: Exists
        tolerationSeconds: 120
      - effect: NoExecute
        key: node.kubernetes.io/not-ready
        operator: Exists
        tolerationSeconds: 120
    image: registry.dsal:8443/mirror/redhat/redhat-marketplace-index:v4.11
    publisher: Custom
    sourceType: grpc
    updateStrategy:
      registryPoll:
        interval: 10m0s
- apiVersion: operators.coreos.com/v1alpha1
  kind: CatalogSource
  metadata:
    name: mirror-redhat-operators
    namespace: openshift-marketplace
  spec:
    displayName: Mirror Red Hat Operators
    grpcPodConfig:
      nodeSelector:
        kubernetes.io/os: linux
        node-role.kubernetes.io/master: ""
      tolerations:
      - effect: NoSchedule
        key: node-role.kubernetes.io/master
        operator: Exists
      - effect: NoExecute
        key: node.kubernetes.io/unreachable
        operator: Exists
        tolerationSeconds: 120
      - effect: NoExecute
        key: node.kubernetes.io/not-ready
        operator: Exists
        tolerationSeconds: 120
    image: registry.dsal:8443/mirror/redhat/redhat-operator-index:v4.11
    publisher: Custom
    sourceType: grpc
    updateStrategy:
      registryPoll:
        interval: 10m0s

  • and then apply:

    oc apply -f 7-default-catalogsources.yaml

Now, we can see our custom catalogs based on default catalogs running:

$ oc get pod -n openshift-marketplace
NAME                                    READY   STATUS    RESTARTS   AGE
marketplace-operator-6f9748c96f-bwlkq   1/1     Running   0          10m
mirror-certified-operators-6dnw9        1/1     Running   0          71s
mirror-community-operators-cx84l        1/1     Running   0          71s
mirror-redhat-marketplace-ct22n         1/1     Running   0          71s
mirror-redhat-operators-4n2q8           1/1     Running   0          71s

$ oc get catalogsource -A
NAMESPACE               NAME                         DISPLAY                      TYPE   PUBLISHER   AGE
openshift-marketplace   mirror-certified-operators   Mirror Certified Operators   grpc   Custom      91s
openshift-marketplace   mirror-community-operators   Mirror Community Operators   grpc   Custom      91s
openshift-marketplace   mirror-redhat-marketplace    Mirror Red Hat Marketplace   grpc   Custom      91s
openshift-marketplace   mirror-redhat-operators      Mirror Red Hat Operators     grpc   Custom      91s
Take note our catalogs have prefix mirror-*

Let’s go to the third method:

Custom catalog

The above 2 methods allow us to have all operators available as we have a connected installation, but the third option involves in creating our custom catalog containing only the operators we need.

Now, catalogs are file-based catalogs instead of sqlite-based catalogs, so most of the command from opm binary don’t work. To create a custom catalog follow next steps:

  • Create catalog index dir

    rm -Rf custom-catalog; mkdir -p custom-catalog/configs

  • Extract render index from public image of a public catalog, in our case, the "redhat-operator" catalog index:

    opm render registry.redhat.io/redhat/redhat-operator-index:v4.11 > redhat-operator-index.json

    Take a look to the json file extracted. You can see all info about channels, packages, operators, …​

    if you have space problems in /tmp you can try to extend /tmp LV

    lvresize --resizefs -L+5G rootvg/tmplv

  • Now we will filter operators from the rendered json extracted from catalog executing an script. These is the list of operators:

    • elasticsearch-operator

    • cluster-logging

    • cincinnati-operator

  • The following script extracts the packages and operators related to the list above:

    operators="elasticsearch-operator cluster-logging cincinnati-operator"
echo "" > custom-catalog/configs/index.json
for operator in $operators; do
  mkdir -p custom-catalog/configs/$operator
  cat redhat-operator-index.json | jq --arg operator "$operator" 'select( .package == $operator or .name == $operator)' >> custom-catalog/configs/$operator/catalog.json
done

  • Now, we generate the dockerfile of our catalog image

    opm generate dockerfile custom-catalog/configs

    This command generate a Dockerfile like this:

    $ more custom-catalog/configs.Dockerfile
# The base image is expected to contain
# /bin/opm (with a serve subcommand) and /bin/grpc_health_probe
FROM quay.io/operator-framework/opm:latest

# Configure the entrypoint and command
ENTRYPOINT ["/bin/opm"]
CMD ["serve", "/configs", "--cache-dir=/tmp/cache"]

# Copy declarative config root into image at /configs and pre-populate serve cache
ADD configs /configs
RUN ["/bin/opm", "serve", "/configs", "--cache-dir=/tmp/cache", "--cache-only"]

# Set DC-specific label for the location of the DC root directory
# in the image
LABEL operators.operatorframework.io.index.configs.v1=/configs

  • Let’s build the catalog image

    cd custom-catalog
podman build -t registry.dsal:8443/mirror/redhat/custom-redhat-operator-index:v1 -f configs.Dockerfile
cd ~/

  • And now, push the catalog image to our registry

    podman push --tls-verify=false \
  --authfile ~/pull-secret-all.json \
  registry.dsal:8443/mirror/redhat/custom-redhat-operator-index:v1

  • Delete all catalogs we deploy in the previous method (we had our mirror-* catalogs)

    oc delete catalogsources --all -n openshift-marketplace

  • Create catalogsource 7-custom-catalogsource.yaml

    apiVersion: operators.coreos.com/v1alpha1
kind: CatalogSource
metadata:
  name: custom-redhat-operators
  namespace: openshift-marketplace
spec:
  displayName: Custom Red Hat Operators
  grpcPodConfig:
    nodeSelector:
      kubernetes.io/os: linux
      node-role.kubernetes.io/master: ""
    tolerations:
    - effect: NoSchedule
      key: node-role.kubernetes.io/master
      operator: Exists
    - effect: NoExecute
      key: node.kubernetes.io/unreachable
      operator: Exists
      tolerationSeconds: 120
    - effect: NoExecute
      key: node.kubernetes.io/not-ready
      operator: Exists
      tolerationSeconds: 120
  image: registry.dsal:8443/mirror/redhat/custom-redhat-operator-index:v1
  publisher: Custom
  sourceType: grpc
  updateStrategy:
    registryPoll:
      interval: 10m0s

  • and apply it

    oc apply -f  7-custom-catalogsource.yaml

Now we can see running our pod, catalog and only our operators selected

$ oc get pod -n openshift-marketplace
NAME                                    READY   STATUS    RESTARTS   AGE
custom-redhat-operators-82z9h           1/1     Running   0          59s
marketplace-operator-6f9748c96f-bwlkq   1/1     Running   0          44m

$ oc get catalogsource -n openshift-marketplace
NAME                      DISPLAY                    TYPE   PUBLISHER   AGE
custom-redhat-operators   Custom Red Hat Operators   grpc   Custom      71s

$ oc get packagemanifest -n openshift-marketplace
NAME                          CATALOG                    AGE
elasticsearch-operator        Custom Red Hat Operators   91s
cluster-logging               Custom Red Hat Operators   91s
cincinnati-operator           Custom Red Hat Operators   91s

Congratulations!! You are provider of your own operators Catalog :)

Disconnected Operators

Now, we have our custom catalog running in our cluster, and operators "available" to be installed, but, we need images neeeded by those operators to able to be deployed, installed and instanced. Those images are:

  • The bundle image

  • Images used by operator to give that service

We have again 2 methods for mirroring this:

  • with oc

  • with oc-mirror

Let’s start with oc method:

Mirroring with oc

This method, nowadays only works with the default catalog index (not custom ones). With custom index you must use oc-mirror. But we will do a dry-run so you can learn how to do it.

We are NOT going to mirror all images of a public catalog (we don’t have enough space in our private registry), but we can see the manifest (--manifest-only parameter) to understand the process:

Execute command and explore directory mapping.txt and ImageContentSourcePolicy file:

oc adm catalog mirror --dry-run --manifests-only registry.redhat.io/redhat/redhat-operator-index:v4.11 registry.dsal:8443/mirror/redhat

The output of this command will be something like this:

src image has index label for declarative configs path: /configs/
using index path mapping: /configs/:/tmp/3682376003
W0118 10:50:52.582735 1061475 manifest.go:449] Chose linux/amd64 manifest from the manifest list.
wrote declarative configs to /tmp/3682376003
using declarative configs at: /tmp/3682376003
no digest mapping available for registry.redhat.io/redhat/redhat-operator-index:v4.11, skip writing to ImageContentSourcePolicy
wrote mirroring manifests to manifests-redhat-operator-index-1674039050
deleted dir /tmp/3682376003

The resultant files are:

$ tree manifests-redhat-operator-index-1674039050/
manifests-redhat-operator-index-1674039050/
├── catalogSource.yaml
├── imageContentSourcePolicy.yaml
└── mapping.txt

These files are:

  • A catalogsource to import in our cluster

  • A ImageContentSourcePolicy to say our cluster where are the images

  • A mapping.txt in format compatible to mirror with the command "oc mirror". We could use it afterwards to do the mirroring.

The method is with oc-mirror:

Mirroring with oc-mirror

This method we use oc-mirror binary, tool which we have used several times in this workshop. oc-mirror helped us to do mirror of set of openshift release images, mirror of images, and also we can use it for catalogs.

oc-mirror offers 2 options:

  • Mirroring with our custom catalog image already filtered with the operators wished.

  • Mirroring with the public catalog image filtering with the imageset syntax

First option:

ImageSet for custom catalog index

This option, oc-mirror takes our custom catalog and also the source/origin catalog (it’s a requirement), makes the mirror of the operators included in our custom catalog and then give to us all we need to run operators in our cluster. Let’s see:

  • Create imageset config file 7-imageset-mirroring-custom-catalog.yaml:

    kind: ImageSetConfiguration
apiVersion: mirror.openshift.io/v1alpha2
archiveSize: 10
storageConfig:
  registry:
    imageURL: registry.dsal:8443/imagetset/mirror-custom-catalog:metadata
    skipTLS: true
mirror:
  operators:
  - catalog: registry.dsal:8443/mirror/redhat/custom-redhat-operator-index:v1
    originalRef: registry.redhat.io/redhat/redhat-operator-index:v4.11
    take note we need to specify in the config the source of our custom catalog with the parameter originalRef

  • Run mirror

    oc-mirror --continue-on-error --config=./7-imageset-mirroring-custom-catalog.yaml  docker://registry.dsal:8443/mirror

    It takes some time, be patient. These will be the output:

    ...
sha256:e72c3703a5be273bd6135626abe6d1a78a3c642eea9c98e508d71cd252d2536a registry.dsal:8443/mirror/openshift-logging/elasticsearch-operator-bundle:33b087fb
sha256:f6af35418dc282c51902b462c03a6fe62d38d0ec83b9fd7c95cee754377b24af registry.dsal:8443/mirror/openshift-logging/elasticsearch-operator-bundle:a9ad14a9
sha256:88223a315adef617e57a038cf825ac2b52a255d64e63b7461ab15e1f7683baf5 registry.dsal:8443/mirror/openshift-logging/elasticsearch-operator-bundle:b0cde4fb
info: Mirroring completed in 4m16.05s (41.98MB/s)
Rendering catalog image "registry.dsal:8443/mirror/mirror/redhat/custom-redhat-operator-index:v1" with file-based catalog
Writing image mapping to oc-mirror-workspace/results-1679995563/mapping.txt
Writing CatalogSource manifests to oc-mirror-workspace/results-1679995563
Writing ICSP manifests to oc-mirror-workspace/results-1679995563

    The result of this operation will be:

    • Operators from custom catalog images mirrored

    • An ImageContentSourcePolicy file to import into the cluster (oc-mirror-workspace/results-xxxx/imageContentSourcePolicy.yaml)

    • A catalogsource with a copy of our catalogsource (oc-mirror-workspace/results-xxxx/catalogSource-redhat-custom-redhat-operator-index.yaml)

    • A mapping.txt with the list of images mirrored (oc-mirror-workspace/results-xxxx/mapping.txt)

We are not going to configure or apply these configuration/mirroring in the cluster. We will do it later, in the next section, with the other option based on the official catalog filtered:

ImageSet for official catalog filtered

The second method/option is using the feature of oc-mirror to filter operators of a default/official index, and mirror images of them.

  • Create imageset config file 7-imageset-mirroring-default-catalog.yaml:

    kind: ImageSetConfiguration
apiVersion: mirror.openshift.io/v1alpha2
archiveSize: 10
storageConfig:
  registry:
    imageURL: registry.dsal:8443/imagetset/mirror-default-catalog:metadata
    skipTLS: true
mirror:
  operators:
   - catalog: registry.redhat.io/redhat/redhat-operator-index:v4.11
     packages:
       - name: elasticsearch-operator
       - name: cluster-logging
       - name: cincinnati-operator

  • Now, delete all catalogs deployed and run oc-mirror command:

    oc delete catalogsource --all -n openshift-marketplace

oc-mirror --continue-on-error --config=./7-imageset-mirroring-default-catalog.yaml docker://registry.dsal:8443/mirror
    .........
.........
info: Mirroring completed in 2.26s (0B/s)
Rendering catalog image "registry.dsal:8443/mirror/redhat/redhat-operator-index:v4.11" with file-based catalog
Writing image mapping to oc-mirror-workspace/results-1674048845/mapping.txt
Writing CatalogSource manifests to oc-mirror-workspace/results-1674048845
Writing ICSP manifests to oc-mirror-workspace/results-1674048845
    Make sure to remember the name of the directory that contains your generated results, which should be named results-xxxx. In the provided example, the directory is named oc-mirror-workspace/results-1674048845.

    The result will be:

    • Operators images mirrored

    • An ImageContentSourcePolicy file to import into the cluster (oc-mirror-workspace/results-xxxx/imageContentSourcePolicy.yaml)

    • A CatalogSource file to create the catalog in the cluster(oc-mirror-workspace/results-xxxx/catalogSource-redhat-custom-redhat-operator-index.yaml)

    • A mapping.txt with the list of images mirrored (oc-mirror-workspace/results-xxxx/mapping.txt)

  • Now, we are going to import the new catalog created by oc-mirror and import the ImageContentSourcePolicy object. Import all object in the folder specified in the output of the oc-mirror execution (use your result dir):

    $ oc apply -f oc-mirror-workspace/results-xxxx
catalogsource.operators.coreos.com/redhat-operator-index created
imagecontentsourcepolicy.operator.openshift.io/operator-0 created

  • The result of all these operations:

    $ oc get pod,catalogsources,packagemanifest,imagecontentsourcepolicy -n openshift-marketplace
NAME                                        READY   STATUS    RESTARTS   AGE
pod/marketplace-operator-6f9748c96f-bwlkq   1/1     Running   0          3h38m
pod/redhat-operator-index-5vp2s             1/1     Running   0          2m25s

NAME                                                       DISPLAY   TYPE   PUBLISHER   AGE
catalogsource.operators.coreos.com/redhat-operator-index             grpc               2m25s

NAME                                                                   CATALOG   AGE
packagemanifest.packages.operators.coreos.com/cincinnati-operator                2m25s
packagemanifest.packages.operators.coreos.com/elasticsearch-operator             2m25s
packagemanifest.packages.operators.coreos.com/cluster-logging                    2m25s

NAME                                                            AGE
imagecontentsourcepolicy.operator.openshift.io/image-policy-0   21h
imagecontentsourcepolicy.operator.openshift.io/image-policy-1   21h
imagecontentsourcepolicy.operator.openshift.io/operator-0       2m25s
    For more detail and stay curious take a look to the files generated by oc-mirror command

To test the the catalogs, mirrors and operators, we will install Openshift Logging Operator and ElasticSearch Operator.

  • Create a yaml file 7-operator-openshift-logging.yaml with the namespaces, the operator groups and subscriptions:

    ---
apiVersion: v1
kind: Namespace
metadata:
  name: openshift-operators-redhat
  annotations:
    openshift.io/node-selector: ""
  labels:
    openshift.io/cluster-monitoring: "true"
---
apiVersion: v1
kind: Namespace
metadata:
  name: openshift-logging
  annotations:
    openshift.io/node-selector: ""
  labels:
    openshift.io/cluster-monitoring: "true"
---
apiVersion: operators.coreos.com/v1
kind: OperatorGroup
metadata:
  name: openshift-operators-redhat
  namespace: openshift-operators-redhat
spec: {}
---
apiVersion: operators.coreos.com/v1alpha1
kind: Subscription
metadata:
  name: "elasticsearch-operator"
  namespace: "openshift-operators-redhat"
spec:
  channel: "stable"
  installPlanApproval: "Automatic"
  source: "redhat-operator-index"
  sourceNamespace: "openshift-marketplace"
  name: "elasticsearch-operator"
---
apiVersion: operators.coreos.com/v1
kind: OperatorGroup
metadata:
  name: cluster-logging
  namespace: openshift-logging
spec:
  targetNamespaces:
  - openshift-logging
---
apiVersion: operators.coreos.com/v1alpha1
kind: Subscription
metadata:
  name: cluster-logging
  namespace: openshift-logging
spec:
  channel: "stable"
  name: cluster-logging
  source: redhat-operator-index
  sourceNamespace: openshift-marketplace

  • and apply it

    oc apply -f 7-operator-openshift-logging.yaml

    After some time, the operators will be installed

    $ oc get clusterserviceversions -n openshift-logging
NAME                           DISPLAY                            VERSION   REPLACES   PHASE
cluster-logging.5.5.5          Red Hat OpenShift Logging          5.5.5                Succeeded
elasticsearch-operator.5.3.9   OpenShift Elasticsearch Operator   5.3.9                Succeeded

$ oc get pod -n openshift-operators-redhat
NAME                                      READY   STATUS    RESTARTS   AGE
elasticsearch-operator-7685d767d9-jzd85   2/2     Running   0          3m17s

$ oc get pod -n openshift-logging
NAME                                      READY   STATUS    RESTARTS   AGE
cluster-logging-operator-ddd4f964-xrdzt   1/1     Running   0          5m22s

We are not going to install an instance of openshift-logging for capacity reasons. We only have a small single node :)
